TBL13P06-3DL8
Features
- High power and current handing capability
- JESD22-A114-B ESD rating of class 1C per human body model
- Halogen free
- Qualified to AEC-Q101 standards for high reliability
Typical Applications
- Load switch
- Power management functions
- PWM Applications
Mechanical Data
- Case: PDFN3×3-8L
- Molding pound, UL Flammability Classification Rating 94V-0
- Terminals: Matte Tin Plated Leads, Solderable Per MIL-STD-202, Method 208
PDFN3×3-8L
Ordering Information
Part Number TBL13P06-3DL8
Package PDFN3×3-8L
Shipping Quantity 5000 pcs / Tape & Reel
Marking Code 13P06
Maximum Ratings (@ TC = 25°C unless otherwise specified)
Parameter Drain-to-Source Voltage Gate-to-Source Voltage Continuous Drain Current (TC = 25°C) Continuous Drain Current (TC = 100°C) Continuous Drain Current (TA = 25°C)
- 1 Continuous Drain Current (TA = 100°C)
- 1 Pulsed Drain Current (tp = 10μs, TA = 25°C) Single Pulse Avalanche Energy
- 4 Power Dissipation (TC = 25°C) Operating Junction Temperature Range...
