GD32F450VKT6 Overview
Key Specifications
Package: LFQFP
Operating Voltage: 3.3 V
Max Voltage (typical range): 3.6 V
Min Voltage (typical range): 2.6 V
Description
GD32F450xx The GD32F450xx device belongs to the stretch performance line of GD32 MCU Family. It is a new 32-bit general-purpose microcontroller based on the ARM® Cortex®-M4 RISC core with best cost-performance ratio in terms of enhanced processing capacity, reduced power consumption and peripheral set.
Key Features
- It also provides a Memory Protection Unit (MPU) and powerful trace technology for enhanced application security and advanced debug support
- It provides up to 3072 KB on-chip Flash memory and 512 KB SRAM memory
- An extensive range of enhanced I/Os and peripherals connected to two APB buses
- The device operates from a 2.6 to 3.6V power supply and available in –40 to +85 °C temperature range
- Three power saving modes provide the flexi
