HSD062IDW1-A02 Overview
1.1 Introduction HannStar Display model HSD062IDW1-A02 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is posed of a TFT LCD panel, a driving circuit and a back- light system. This TFT LCD has a 6.2 (16:9) inch diagonally measured active display area with 800 horizontal by 480 vertical pixel resolutions.
HSD062IDW1-A02 Key Features
- 6.2 (16:9 diagonal) inch configuration
- 6 bits + FRC driver with 1channel TTL interface
- LED Backlight
- Up/Down, Left/Right reversion selection
- RoHS/ Halogen Free pliance
