HSD160PHW1-B00 - TFT LCD Panel

General Description

B00 Formal Product Specification was first released.

The information contained in this document is the exclusive property of HannStar Display Corporation.

Key Features

  • 16 (16:9 diagonal) inch configuration.
  • One channel LVDS interface.
  • 262K color by 6 bit R. G. B signal input.
  • RoHS Compliance.
  • Halogen Free 1.3.

📥 Download Datasheet

Datasheet Details

Part number HSD160PHW1-B00
Manufacturer HannStar
File Size 459.66 KB
Description TFT LCD Panel
