HT75C0-2 Datasheet 100mA Low Power LDO

Manufacturer: Holtek Semiconductor

Download the HT75C0-2 datasheet PDF. This datasheet also includes the HT75xx-2 variant, as both parts are published together in a single manufacturer document.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (HT75xx-2_HoltekSemiconductor.pdf) that lists specifications for multiple related part numbers.

General Description

The HT75XX-2 series is a set of three-terminal low power high voltage implemented in CMOS technology.

They can deliver 100mA output current and allow an input voltage as high as 24V.

They are available with several fixed output voltages ranging from 2.1V to 12.0V.

Overview

www.DataSheet.co.kr HT75XX-2 100mA Low Power LDO.

Key Features

  • Low power consumption.
  • Low voltage drop.
  • Low temperature coefficient.
  • High input voltage (up to 24V).
  • High output current : 100mA.
  • Output voltage accuracy: tolerance ±1%.
  • TO92, SOT89 and SOT23-5 packages.
