HT75R50-7A
Features
- Low power consumption
- Low voltage dropout
- Low temperature coefficient
- Maximum input voltage: 30V
- Output voltage accuracy: ±2%
- Low Quiescent Current: 2.5μA (typ.)
- High output current: 150m A
- Soft start function
- Over current protection
- Over temperature protection
- Allow 1μF ceramic type output capacitor
- Package types: 3-pin SOT89, 5-pin SOT23
Applications
- Battery-powered equipment
- munication equipment
- Audio/Video equipment
General Description
The HT75Rxx-7 series of devices are low-power high-voltage regulators implemented in CMOS technology, which ensures low voltage dropout and low quiescent current. They allow input voltages as high as 30V and are available with several fixed output voltages ranging from 3V to 12V. The devices include a soft start function, which is used to control the output slew rate to prevent the overshooting phenomenon when power on. The chip enable pin, CE, accepts a CMOS level as logic input. When the CE input is low, a...
