BS23B16CA
Features
CPU Features
- Operating voltage
- BS23A02CA/BS23B04CA/BS23B08CA:
- f SYS=8MHz: 2.0V~5.5V
- BS23B16CA:
- f SYS=8MHz: 1.8V~5.5V
- f SYS=12MHz: 2.7V~5.5V
- f SYS=16MHz: 3.3V~5.5V
- Up to 0.25μs instruction cycle with 16MHz system clock at VDD=5V
- Power down and wake-up functions to reduce power consumption
- Oscillator types
- Internal High Speed 8/12/16MHz RC
- HIRC
- Internal Low Speed 32k Hz RC
- LIRC
- Multi-mode operation: FAST, SLOW, IDLE and SLEEP
- Fully integrated internal oscillators require no external ponents
- All instructions executed in one or two instruction cycles
- Table read instructions
- 61 powerful instructions
- Up to 6-level subroutine nesting
- Bit manipulation instruction
Peripheral Features
- OTP Program Memory: (1K-16)×14~(2K-16)×16
- Data Memory: 64×8~512×8
- OTP ROM Parameter Program
- ORPP (for BS23B04CA, BS23B08CA and BS23B16CA)
- Watchdog Timer function
- Up to 22 bidirectional I/O lines
- Single external interrupt line shared with I/O pin
-...
