HT7121-1 - 30mA Low Power LDO

General Description

The HT71XX-1 series is a set of three-terminal low power high voltage regulators implemented in CMOS technology.

They allow input voltages as high as 24V.

They are available with several fixed output voltages ranging from 2.1V to 5.0V.

Key Features

  • Low power consumption.
  • Low voltage drop.
  • Low temperature coefficient.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
HT7123A 330MHz Triple 10-Bit High Speed Video DAC HTCSEMI
HT7126A 31/2 Digit LCD / A/D Converter HTCSEMI
HT7130 High Voltage Regulator Holtek Semiconductor Inc
HT7133 High Voltage Regulator Holtek Semiconductor Inc
HT7135A 4 1/2-DIGIT PRECISION ANALOG-TO-DIGITAL CONVERTERS HTCSEMI

Other Datasheets by Holtek Semiconductor

Part Number Description
HT7121-2 30mA TinyPower LDO
HT7123-1 30mA Low Power LDO
HT7123-2 30mA TinyPower LDO
HT7125-1 30mA Low Power LDO
HT7125-2 30mA TinyPower LDO

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
HT71XX-1 30mA Low Power LDO Features · Low power consumption · Low voltage drop · Low temperature coefficient Applications · Battery-powered equipment · Communication equipment · High input voltage (up to 24V) · Output voltage accuracy: tolerance ±3% · TO92, SOT89 and SOT23-5 package · Audio/Video equipment General Description The HT71XX-1 series is a set of three-terminal low power high voltage regulators implemented in CMOS technology. They allow input voltages as high as 24V. They are available with several fixed output voltages ranging from 2.1V to 5.0V. CMOS technology ensures low voltage drop and low quiescent current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain variable voltages and currents.
