HT7123-2 - 30mA TinyPower LDO

Download the HT7123-2 datasheet PDF. This datasheet also covers the HT7121-2 variant, as both devices belong to the same 30ma tinypower ldo family and are provided as variant models within a single manufacturer datasheet.

General Description

The HT71xx-2 series is a set of three-terminal low power high voltage regulators implemented in CMOS technology.

They allow input voltages as high as 30V.

They are available with several fixed output voltages ranging from 2.1V to 5.0V.

Key Features

  • Low power consumption.
  • Low voltage drop.
  • Low temperature coefficient.
  • High input voltage (up to 30V).
  • Output voltage accuracy: tolerance ±1%.
  • Package types: 3-pin TO92, 3-pin SOT89 and 5-pin SOT23.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (HT7121-2-Holtek.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
HT7123A 330MHz Triple 10-Bit High Speed Video DAC HTCSEMI
HT7126A 31/2 Digit LCD / A/D Converter HTCSEMI
HT7130 High Voltage Regulator Holtek Semiconductor Inc
HT7133 High Voltage Regulator Holtek Semiconductor Inc
HT7135A 4 1/2-DIGIT PRECISION ANALOG-TO-DIGITAL CONVERTERS HTCSEMI

Other Datasheets by Holtek Semiconductor

Part Number Description
HT7123-1 30mA Low Power LDO
HT7121-1 30mA Low Power LDO
HT7121-2 30mA TinyPower LDO
HT7125-1 30mA Low Power LDO
HT7125-2 30mA TinyPower LDO

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Features • Low power consumption • Low voltage drop • Low temperature coefficient • High input voltage (up to 30V) • Output voltage accuracy: tolerance ±1% • Package types: 3-pin TO92, 3-pin SOT89 and 5-pin SOT23 Applications • Battery-powered equipment • Communication equipment • Audio/Video equipment Selection Table Part No. HT7121-2 HT7123-2 HT7125-2 HT7127-2 HT7130-2 HT7133-2 HT7136-2 HT7144-2 HT7150-2 Output Voltage 2.1V 2.3V 2.5V 2.7V 3.0V 3.3V 3.6V 4.4V 5.0V Note: ″xx″ stands for output voltages. HT71xx-2 30mA TinyPowerTM LDO General Description The HT71xx-2 series is a set of three-terminal low power high voltage regulators implemented in CMOS technology. They allow input voltages as high as 30V. They are available with several fixed output voltages ranging from 2.
