HT7A8006
Description
The HT7A8006 is a controller for implementing constant voltage LED driver with power factor correction (PFC). By using primary-side regulation, it controls the output voltage accurately without the need of secondary side feedback ponents.
Key Features
- Primary-Side Voltage Regulation without Secondary-Side Feedback Circuitry
- Power Factor Higher than 0.9
- Constant Voltage Regulation Less than ±5%
- Full Protection Functions for Enhanced Safety
- Output Over Voltage Protection
- Output Over Load Protection
- VCC Over Voltage Protection
- VCC Under Voltage Lockout
- External/Internal Over Temperature Protection
- Package Type: 8-pin SOP
