HT16K33 Description
The HT16K33 is a memory mapping and multi-function LED controller driver. Display segment numbers in the device is 128 patterns (16 segments and 8 mons) with a 13 3 (MAX.) matrix key scan circuit. The software configuration.
- Part: HT16K33
- Manufacturer: Holtek Semiconductor (official site)
- Size: 666.63 KB
