HT66F03 Description
The devices are Flash Memory type 8-bit high performance RISC architecture microcontrollers. Offering users the convenience of Flash Memory multi-programming.
HT66F03 Key Features
- Operating Voltage: fSYS= 8MHz: 2.2V~5.5V fSYS= 12MHz: 2.7V~5.5V fSYS= 20MHz: 4.5V~5.5V
- Up to 0.2ms instruction cycle with 20MHz system clock at VDD=5V
- Power down and wake-up functions to reduce power consumption
- Five oscillators: External high speed xtal External 32.768kHz xtal External RC Internal high speed -- no external ponent
- Multi-mode operation: NORMAL, SLOW, IDLE and SLEEP
- Fully integrated internal 4MHz, 8MHz and 12MHz oscillator requires no external ponents
- All instructions executed in one or two instruction cycles
- Table read instructions
- 63 powerful instructions
- Up to 8 subroutine nesting levels
