This datasheet includes multiple variants, all published together in a single manufacturer document.
| Part number | BCP53-16 |
|---|---|
| Datasheet | BCP53-16 BCP51 Datasheet (PDF) |
| File Size | 808.20 KB |
| Manufacturer | Infineon |
| Description | PNP Silicon AF Transistors |
|
|
PNP Silicon AF Transistors For AF driver and output stages High collector current Low collector-emitter saturation voltage plementary types: BCP56 (NPN) Pb-free (RoHS pliant) package Qualified according AEC Q101 BCP51...-BCP53... at TA = 25°C, unless otherwise specified Parameter Symbol Values Unit min.
