IP5416 - TWS Bluetooth Earphone Charging Box SOC

Product Overview

Injoinic

📥 Download Datasheet

IP5416 TWS Bluetooth Earphone Charging Box SOC by Injoinic - Datasheet Preview — Datasheet preview – IP5416

Datasheet Details

Part number	IP5416
Manufacturer	Injoinic
File Size	645.47 KB
Description	TWS Bluetooth Earphone Charging Box SOC
Datasheet	IP5416 Datasheet
Additional preview pages of the IP5416 datasheet.

Product details

Description

IP5416 is a multi-functional power management SOC for total solution on TWS Bluetooth Earphone Charging Box.

Features

Discharge.
200mA Synchronous Boost Conversion.
Up to 95%@5V/200mA discharge efficiency of synchronous switch.
Built-in power path management supports charging and discharging at the same time.
Charge.
Max 500mA linear charger, charging current can be customized.
Adjusts charging current automatically to adapt to different load capacity adapters.
Supports 4.20V, 4.30V 4.35V, 4.40V batteries. Standard product 4.20V, other voltages need to be customized.
