BT101IW03-V1 Datasheet | Innolux

Description Plug detection pin Power Supply (+3.3V) Power Supply (+3.3V) DDC Power +3.3V BIST function enable (+3.3V) DDC Clock DDC Data Differential Data Input Differential Data Input Ground Differential Data Input Differential Data Input Ground Differential Data Input Differential Data Input Ground Differential Clock Input Differential Clock Input No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) No connection (Reserve) LED Ground LED Ground LED Ground Plug detection pin PWM dimming signal input LED enable pin (3.3V) No connection (Reserve) LED power supply 6.0V~20V LED power supply 6.0V~20V LED power supply 6.0V~20V Remark R0~R5,G0 G1~G5,B0,B1 B2~B5,DE,Hsync,Vsync ALL RIGHTS STRICTLY RESERVED. ANY PORTION OF THIS DOCUMENT SHALL NOT BE REPRODUCED, COPIED, OR TRANSFORMED...
