IR2113 Datasheet High And Low Side Driver

Manufacturer: International Rectifier (now Infineon)

Overview: Previous Datasheet Index Next Data Sheet Data Sheet No. PD-6.

Datasheet Details

Part number	IR2113
Manufacturer	International Rectifier (now Infineon)
File Size	459.67 KB
Description	HIGH AND LOW SIDE DRIVER
Datasheet	IR2113_InternationalRectifier.pdf

General Description

The IR2113 is a high voltage, high speed power MOSFET and IGBT driver with independent high and low side referenced output channels.

Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction.

Logic inputs are compatible with standard CMOS or LSTTL outputs.

Key Features

n Floating channel designed for bootstrap operation Fully operational to +600V Tolerant to negative transient voltage dV/dt immune n Gate drive supply range from 10 to 20V n Undervoltage lockout for both channels n Separate logic supply range from 5 to 20V Logic and power ground ±5V offset n CMOS Schmitt-triggered inputs with pull-down n Cycle by cycle edge-triggered shutdown logic n Matched propagation delay for both channels n Outputs in phase with inputs Product Summary.
