ISA1603AM1
DESCRIPTION
ISA1603AM1 is a mini package resin sealed silicon PNP epitaxial transistor,
It is designed for low frequency voltage application.
FOR LOW FREQUENCY AMPLIFY APPLICATION SILICON PNP EPITAXIAL TYPE
OUTLINE DRAWING
2.1 0.425 1.25 0.425
Unit：ｍｍ
2.0 1.3 0.65 0.65
FEATURE
- Small collector to emitter saturation voltage. VCE(sat)=-0.3V max（@IC=-100m A/IB=-10m A）
- Excellent linearity of DC forward current gain.
- Super mini package for easy mounting.
①
②
③
0.9 0.7 0～0.1 0.15
APPLICATION
For small type machine low frequency voltage amplify application
MAXIMUM RATINGS（Ta=25℃）
Parameter
Symbol
Collector to Base voltage
VCBO
Emitter to Base voltage
VEBO
Collector to Emitter voltage
VCEO
Collector current
Collector dissipation
Junction temperature
Tj
Storage temperature
Tstg
Ratings
Unit
-60...
