RT1P14BU
DESCRIPTION
RT1P14BX is a one chip transistor with built-in bias resistor, NPN type is RT1N14BX.
FEATURE
- Built-in bias resistor (R2=10kΩ).
APPLICATION
Inverted circuit, switching circuit, interface circuit, driver circuit.
2.8 1.90 0.95 0.95
〈Transistor〉
Transistor With Resistor For Switching Application Silicon PNP Epitaxial Type
OUTLINE DRAWING UNIT：mm
RT1P14BC 2.8
0.65 1.5 0.65
①
②
③
1.1 0.8 0～0.1 0.13
0.4 7.5MAX
1.7 1.0 0.5 0.5
0.22 0.32
Equivalent circuit
C (OUT) B (IN) R2
E (GND)
1.5 0.35 0.8 0.35
①
②
③
JEITA：SC-75A JEDEC：－
Terminal Connector ①：Base ②：Emitter ③：Collector
0.9 0.7 0～0.1
2.0 1.3 0.65 0.65
RT1P14BM
2.1 0.425 1.25 0.425
①
②
③
JEITA：SC-70 JEDEC：－
Terminal Connector ①：Base ②：Emitter ③：Collector
0.15...
