JINAN JINGHENG ELECTRONICS SS520LC
LOW VF SCHOTTKY BARRIER RECTIFIER
| Part No. | SS520LC |
|---|---|
| Datasheet | SS520LC Download |
| Manufacturer |  JINAN JINGHENG ELECTRONICS |
| Description | LOW VF SCHOTTKY BARRIER RECTIFIER |
| Buy | Stock & Price |
FEATURES
Plastic package has Underwriters Laboratory Flammability Classification 94V-0 Metal silicon junction ,majority carrier conduction Guard ring for overvoltage protection Low power loss ,high efficiency High current capability ,low forward voltage drop High surge capability Pb RoHS COMPLIANT High temperature soldering guaranteed:260℃/10 seconds at terminals Component in accordance to RoHS 2015/863/EU SJSF2SS15J0F2L0LCMECHANICAL DATA
Case: JEDEC SMC(DO-214AB) molded plastic body Terminals: solder plated ,solderable per MIL-STD-750,method 2026 Polarity: color band denotes cathode end Weight: 0.007ounce,0.21 gram SMC(DO-214AB) 0.128(3.25) 0.108(2.75) 0.245(6.22) 0.220(5.59) 0.280(7.11) 0.260(6.60) 0.103(2.62) 0.079(2.00) 0.060(1.52) 0.030(0.76) 0.320(8.13) 0.305(7.75) 0.012(0.305) 0.006(0.152) 0.008(0.203) MAX Suggested PAD Layout 0.185(4.69)MAX 0.128(3.25)MINTYPICAL APPLICATIONS
For use in low voltage ,high frequency inverters ,DC/DC converters, free wheeling ,and polarity protec...
