KD SR05
LOW CAPACITANCE TVS ARRAY / ESD ARRAY
| Part No. | SR05 |
|---|---|
| Datasheet | SR05 Download |
| Manufacturer |  KD |
| Description | LOW CAPACITANCE TVS ARRAY / ESD ARRAY |
| Buy | Stock & Price |
FEATURES
● ESD protection to IEC 61000-4-2 (ESD) ±15kV (air), ±8kV (contact) IEC 61000-4-4 (EFT) 40A (5/50ns) IEC 61000-4-5 (Lightning) 24A (8/20µs)● Array of surge rated diodes with internal TVS Diode
● Protects two I/O lines
● Low capacitance (<10pF) for high-speed interfaces
● Low clamping voltage
● Low operating voltage: 5.0V
● Solid-state silicon-avalanche technology
APPLICATIONS
● USB Power & Data Line Protection● Ethernet 10BaseT
● I2C Bus Protection
● Video Line Protection
● T1/E1 secondary IC Side Protection
● Portable Electronics
● Microcontroller Input Protection
● WAN/LAN Equipment
● ISDN S/T Interface SOT-143 Pin Configuration 4 3 1 2 Absolute Maximum Rating (Tamb=25°C unless otherwise specified) Rating Symbol Value Peak Pulse Power (tp = 8/20μs) Peak Pulse Current (tp = 8/20μs) Ppk 500 IPP 25 ESD per IEC 61000-4-2 (Air) ESD per IEC 61000-4-2 (Contact) VESD 15 8 Lead Soldering Temperature Operating Temperature Storage Temperature TL TJ TSTG 260 (10 sec.) -55 to +125 -55...
