Datasheet Summary
8A SENSITIVE SCRs
BT150 Series
- Description: Highly sensitive triggering levels,the BT150 Series SCRs is suitable for all applications,where the available gate currentis limited,such as capacitive discharge ignitions,motor control in kitchen aids, overvoltage crowbar protection in low power supplies...
- Features
: Blocking voltage to 500V On-state RMS current to 8A Non-repetitive peak on-state current to 70A
-...
