FEATURES
ƽ Small package TranDsiisotdoerss High Speed Switching Diode 1SS387 SOD-523 1.2 +0.1 - 0.1 + - +0.05 0.3 - 0.05 Unit:mm 0.6 +0.1 -0.1 +0.05 0.8 -0.05 1 1.6 +0.1 - 0.1 0.77max +0.05 0.1 -0.02 0.07max 2 Ƶ ABSOLUTE MAXIMUM RATINGS
Ta = 25ć Parameter Peak Reverse Voltage DC Blocking Voltage Average Rectified Output Current Peak Forward Surge Current Surge Current (t=10ms) Junction Temperature Storage Temperature range Symbol Rating Unit VRM 85 V VR 80 Io 100 IFM 200 mA Isurge 1000 TJ 150 ć Tstg -55 to 150 Ƶ ELECTRICAL CHARACTERISTICS
Ta = 25ć Parameter Reverse breakdown voltage Forward voltage Reverse voltage leakage current Capacitance between terminals Reverse recovery time Symbol Test Conditions VR IR= 100 uA VF1 IF= 1 mA VF2 IF= 10mA VF3 IF= 100 mA IR1 VR=30 V IR2 VR=80 V CT VR= 0 V, f= 1 MHz trr VR=6V, IF=10mA, RL=100ȍ Min Typ Max Unit 85 0.62 V 0.75 1.2 0.1 uA 0.5 3 pF 4 ns Ƶ Marking Marking A1 1
