2PB709A - PNP General Purpose Transistor

Key Features

  • Low current (max. 100 mA) Low voltage (max. 45 V). +0.1 2.4 -0.1 SOT-23 2.9+0.1 -0.1 0.4+0.1 -0.1 3 1 2 0.95+0.1 -0.1 1.9+0.1 -0.1 Absolute Maximum Ratings Ta = 25 Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current (DC) Peak collector current Peak base current Total power dissipation(Tamb 25 ;.
  • ) Storage temperature Junction temperature Operating ambient temperature Thermal resistance from junction to ambient.
  • Transistor mounted on an.
