2SC2412
Features
Low Cob.Cob=2.0p F (Typ.)
+0.1 2.4 -0.1
SOT-23
2.9 +0.1 -0.1
0.4 +0.1 -0.1
0.95 +0.1 -0.1 1.9 +0.1 -0.1
+0.1 1.3 -0.1
+0.1 0.97 -0.1
Unit: mm
0.1 +0.05 -0.01
1.Base 2.Emitter 3.collector
0-0.1 +0.1 0.38
-0.1
Absolute Maximum Ratings Ta = 25
Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current Collector power dissipation Junction temperature Storage temperature
Symbol
Rating
Unit
VCBO
VCEO
VEBO
Tj
Tstg
-55 to +150
Electrical Characteristics Ta = 25
Parameter Collector- base breakdown voltage Collector- emitter breakdown voltage Emitter
- base breakdown voltage Collector-base cut-off current Emitter cut-off current Collector-emitter saturation voltage Base
- emitter saturation voltage DC current gain Collector output capacitance Transition...
