2SC3649
Features
- High breakdown voltage and large current capacity.
- plementary to 2SA1419
1.70 0.1
0.42 0.1
0.46 0.1
- Absolute Maximum Ratings Ta = 25℃
Parameter Collector
- Base Voltage Collector
- Emitter Voltage Emitter
- Base Voltage Collector Current
- Continuous Peak Collector Current Collector Power Dissipation Junction Temperature Storage Temperature Range
Symbol VCBO VCEO VEBO IC ICM PC TJ Tstg
Rating 180 160 6 1.5 2.5 500 150
-55 to 150
- Electrical Characteristics Ta = 25℃
Parameter
Symbol
Test Conditions
Collector- base breakdown voltage Collector- emitter breakdown voltage
VCBO VCEO
Ic= 100 μA， IE= 0 Ic= 1 m A，RBE= ∞
Emitter
- base breakdown voltage
VEBO IE= 100μA， IC= 0
Collector-base cut-off current
ICBO VCB= 120 V , IE= 0
Emitter cut-off current
IEBO VEB= 4V , IC=0
Collector-emitter saturation voltage
VCE(sat) IC=500m A, IB=50m A
Base
- emitter saturation voltage
VBE(sat) IC=500m A, IB=50m A
DC current gain
VCE= 5V, IC= 100m A h FE
VCE= 5V, IC= 10m...
