FEATURES
Very low output-on resistance (Ron). Low capacitance. ABSOLUTE MAXIMUM RATINGS
Ta = 25 Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current Collector power dissipation Junction temperature Storage temperature Symbol Rating Unit VCBO 12 V VCEO 6 V VEBO 3 V IC 50 mA PC 0.2 W Tj 150 Tstg -55 to +150 1 Emitter 2 Base 3 Collector ELECTRICAL CHARACTERISTICS
Ta = 25 Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector cutoff current Emitter cutoff current Collector-emitter saturation voltage Forward current transfer ratio Transition frequency Output capacitance Output-on resistance Symbol Testconditons BVCBO IC=10ìA BVCEO IC=1mA BVEBO IE=10ìA ICBO VCB=10V IEBO VEB=2V VCE(sat) IC/IB=10mA/1mA hFE VCE/IC=5V/5mA fT VCE=5V, IE= -10mA, f=200MHz Cob VCB=10V, IE=0A, f=1MHz Ron IB=3mA, VI=100mVrms, f=500kHz Min Typ Max Unit 12 V 6 V 3 V 0.5 ìA 0.5 ìA 0.3 V 270 560 300 800 MHz 1 1.7 pF 2 Ù Marking Marking BMS 1
