FEATURES
High voltage current controlled RF resistor for RF attenuator and swirches Freqency range above 1 MHz Low resistance and short carrier lifetime For frequencies up to 3 GHz SOD-323 1.7+0.1 -0.1 Unit: mm 0.85+0.05 -0.05 +0.05 0.3 -0.05 +0.1 1.3 -0.1 2.6+0.1 -0.1 0.475 0.375 1.0max +0.05 0.1 -0.02 Absolute Maxim um Ratings Ta = 25 P aram eter Symbol Reverse voltage VR Forward current IF Total Power dissipation TS 25 P tot Junction temperature Tj Operating temperature range Top Storage temperature range Tstg Junction - soldering point1) RthJA Note: 1.Package mounted on alumina 15mm x 16.7mm x 0.7mm Value 200 100 250 150 -55 to +150 -55 to +150 450 Unit V mA mW K/W ELECTRICAL CHARACTERISTICS
Ta = 25 Parameter Breakdown voltage Forward voltage Diode capacitance Symbol V(BR) VF CT Forward resistance rf Charge carrier life time rr Series inductance Ls Conditions IR = 5 A VR = 20 V, f = 1 MHz VR = 0 V, f = 100 MHz IF = 1 mA, f = 100 MHz IF = 10 mA, f = 100 MHz IF = 100 mA, f = 100 MHz...
