BAR64-06W
Features
ƽ High voltage current controlled ƽ RF resistor for RF attenuator and swirches ƽ Freqency range above 1 MHz ƽ Low resistance and short carrier lifetime ƽ For frequencies up to 3 GHz
BAR64W
BAR64-05W
BAR64-04W
Ƶ Absolute Maximum Ratings Ta = 25ć
Parameter Peak Reverse Voltage
Forward Current
BAR64W Power Dissipation
BAR64-04W/05W/06W Thermal Resistance Junction to Ambient
@ Ts İ 90°C @ Ts İ 65°C
BAR64W
BAR64-04W/05W/06W
Thermal Resistance Junction to Soldering Point BAR64W BAR64-04W/05W/06W
Junction Temperature
Operating Temperature Range Storage Temperature range
Symbol VR IF PD
RșJA
RșJS TJ Top Tstg
Rating 200 100
320 500 240 340 150 -55 to 150 -55 to 150
Unit V m A m W
ć/W
ć
Ƶ Electrical Characteristics Ta = 25ć
Parameter Reverse breakdown voltage Forward voltage Reverse voltage leakage current
Forward resistance
Series inductance Capacitance between terminals Reverse recovery time
Symbol
Test Conditions
VR IR= 100u A
VF IF= 50 m A
IR1 VR=200...
