BAR66
Features
Surge protection device Two PIN diodes, series configuration Designed for surge overvoltage clamping in antiparallel connection
+0.1 2.4 -0.1
SOT-23
2.9+0.1 -0.1
0.4+0.1 -0.1
0.95+0.1 -0.1 1.9+0.1 -0.1
+0.1 1.3 -0.1
Unit: mm 0.1+0.05
-0.01
+0.1 0.97 -0.1
Absolute M axim um Ratings Ta = 25
Param eter Reverse voltage Forward current Forward current (tp = 1 S) Power dissipation, TS 25 1) Operating tem perature range Storage tem perature range Junction
- am bient 1) Note 1. Package m ounted on alum ina 15m m
Sym bol VR IF IF P tot Top T stg
R th JA
V a lu e 150 200 20 250
-55 to +150 -55 to +150
16.7m m 0.7m m
U n it V m A A m W
K/W
Electrical Characteristics Ta = 25
P aram eter
Symbol
Test Condition
Min
Reverse leakage
IR = 5 A
Forward voltage
IF = 50 m A
VR = 35 V, f = 1...
