CZT5551
Features
- High Voltage
- High Voltage Amplifier Application
SOT-223
6.50±0.2 3.00±0.1
7.0±0.3 3.50±0.2
10b
Unit:mm
- Absolute Maximum Ratings Ta = 25℃
Parameter Collector
- Base Voltage Collector
- Emitter Voltage Emitter
- Base Voltage Collector Current
- Continuous Collector Power Dissipation Thermal Resistance From Junction To Ambient Junction Temperature Storage Temperature Range
Symbol VCBO VCEO VEBO IC PC RθJA TJ Tstg
1.80 (max) 0.02 ~ 0.1
2.30 (typ) 4.60 (typ)
0.70±0.1
0.250 Gauge Plane
1.Base 2.Collector 3.Emitter 4.Collector
Rating 180 160 6 0.6 1 125 150
-55 to 150
Unit
A W ℃/W ℃
- Electrical Characteristics Ta = 25℃
Parameter Collector- base breakdown voltage Collector- emitter breakdown voltage Emitter
- base breakdown voltage Collector-base cut-off current Emitter cut-off current Collector-emitter saturation voltage
Base
- emitter saturation voltage
DC current gain
Collector output capacitance Emitter input capacitance Transition...
