DAP202K
Features
- Ultra high speed switching
- High reliability
Switching Diodes DAP202K (KAP202K)
SOT-23
2.9 +0.1 -0.1
0.4 +0.1 -0.1
+0.1 2.4 -0.1
0.95 +0.1 -0.1
1.9 +0.1 -0.1
+0.1 1.3 -0.1
Diodes
Unit: mm 0.1 +0.05
-0.01
+0.1 0.97 -0.1
0-0.1 +0.1 0.38
-0.1
- Absolute Maximum Ratings Ta = 25℃
Parameter Reverse Voltage Reverse Voltage (DC) Average rectified forward current (Single) Average rectified forward current (double) Forward Current (Single) Forward Current (Double) Surge current (t=1us) (Single) Surge current (t=1us) (Double) Power Dissipation Thermal Resistance Junction to Ambient Junction Temperature Storage Temperature range
Symbol VRM VR Io
Isurge
Pd RθJA
TJ Tstg
Rating 80 80 100 150 300 450 4 6 200 556 150
-55 to 150
Unit V m A
A m W ℃/W ℃
- Electrical Characteristics Ta = 25℃
Parameter Reverse breakdown voltage Forward voltage Reverse voltage leakage current Capacitance between terminals Reverse recovery time
Symbol
Test...
