HR1L3N Datasheet Digital Transistors

Manufacturer: Kexin Semiconductor

Overview: SMD Type Digital Transistors HR1L3N Transistors.

Key Features

  • Up to 2A High Current Drives Such As IC Outputs and Actuators Available On-chip Bias Resistor Low Power Consumption During Drive Absolute Maximum Ratings Ta = 25 Parameter Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Collector Current (DC) Collector Current (Pulse) Base Current (DC) Total Power Dissipation Junction temperature Storage temperature Symbol Rating Unit VCBO -60 V VCEO -60 V VEBO -10 V IC(DC) -1.0 A IC(pulse).
  • 1 -2.0 A IB(DC) -0.02.
