L1N4148WT1G
Features
- Fast Switching Speed
- For General Purpose Switching Applications.
- High Conductance
- Surface Mount Package Ideally Suited for
Automatic Insertion
- Pb-Free package is available
SOD-123
2.7 +0.1
- 0.1
3.7 +0.1
- 0.1 0.35
+0.1 0.55
- 0.1
+0.1 1.6
- 0.1
Diodes
Unit:mm
1.1 +0.05
- 0.05 0.1max
+0.05 0.1 -0.02
Cathode
Anode
- Absolute Maximum Ratings Ta = 25℃
Parameter Non-Repetitive Peak Reverse Voltage Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Average Rectified Output Current Repetitive Rectified Output Current
Non-Repetitive Peak Forward Surge Current
Power Dissipation Thermal Resistance Junction to Ambient Junction Temperature Storage Temperature range t=1us t=1s
Symbol VRM VRRM VRWM VR
VR(RMS) Io IFM
IFSM
PD RθJA
TJ Tstg
Rating 100
53 200 300
2 1 425 290 150 -65 to...
