MSQA6V1W5T2G
Features
- Low Clamping Voltage
- Stand Off Voltage 3 V
- Low Leakage < 1A @ 3 V
- IEC1000- 4- 2 Level 4 ESD Protection
- Pb- Free Package is Available
SOT-353
1.3 +0.1 -0.1
0.3 +0.1 -0.1
2.1 +0.1 -0.1
+ 0.95 0.05
- 0.05
0.1m ax
+0.15 2.3
- 0.15
+0.1 0.36
- 0.1
Diodes
Unit: mm
0.1 +0.05 -0.02
+ 1.25 0.1
- 0.1
- Absolute Maximum Ratings Ta = 25℃
Parameter ESD Discharge @ MIL STD 883C
- Method 3015- 6
IEC1000- 4- 2, Air Discharge IEC1000- 4- 2, Contact Discharge Steady State Power
- 1 Diode Peak Power Dissipation @ 20us Thermal Resistance Junction to Ambient Above 25℃, Derate Lead Solder Temperature (10 s duration) Junction Temperature Storage Temperature...
