Kexin Electronics PD3S130L
Schottky Diodes
| Part No. | PD3S130L |
|---|---|
| Datasheet | PD3S130L Download |
| Manufacturer | Kexin Electronics |
| Description | Schottky Diodes |
| Buy | Stock & Price |
FEATURES
● Ultra-Small Surface Mount Package● Guard Ring Die Construction for Transient Protection
● High Surge Capability
● Lead Free Finish, RoHS Compliant SOD323F (SC-90) 1.35 1.15 1 2.7 1.8 2.3 1.6 Unit:mm 0.80 0.65 0.5 0.3 2 0.40 0.25 0.25
●
ABSOLUTE MAXIMUM RATINGS
Ta = 25℃ Parameter Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage RMS Reverse Voltage Average Forward Current Non-Repetitive Peak Forward Surge Current @ 8.3mS Thermal Resistance Junction to Ambient Thermal Resistance Junction to Soildering Point Junction Temperature Storage Temperature range Symbol VRRM VRWM VR VR(RMS) IFAV IFSM RθJA RθJS TJ Tstg Rating 30 21 1 22 177 (typ) 6 125 -55 to 150 Unit V A ℃/W ℃/W ℃●
ELECTRICAL CHARACTERISTICS
Ta = 25℃ Parameter Symbol Test Conditions Reverse breakdown voltage VR IR= 1.5 mA Forward voltage VF1 IF= 100 mA VF2 IF= 700 mA VF3 IF= 1 A Reverse voltage leakage current IR1 VR= 5 V IR2 VR=30 V Junction capacitance Cj VR=10 V, f= 1 MHz● Marking Ma...
