PESD24VL2BT
Features
- ESD protection of two lines
- Max. peak pulse power: PPP=350W
- Low clamping voltage: VCL=26V
- Small SMD plastic package
- Ultra low leakage current: IRM<90n A
- ESD protection up to 23 k V
- IEC61000-4-2, level4 (ESD)
- IEC61000-4-5 (surge); IPP=15A
1 3
+0.1 2.4 -0.1
SOT-23
2.9 +0.1 -0.1
0.4 +0.1 -0.1
0.95 +0.1 -0.1 1.9 +0.1 -0.1
+0.1 1.3 -0.1
+0.1 0.97 -0.1
Unit: mm
0.1 +0.05 -0.01
1.cathode1 2.cathode2 3.double cathode
0-0.1 +0.1 0.38
-0.1
- Absolute Maximum Ratings
Parameter
Symbol
PESD PESD PESD PESD PESD 3V3L2BT 5V0L2BT 12VL2BT 15VL2BT 24VL2BT
Unit
IEC61000-4-2 (Note 2,3) Electrostatic dischargevoltage (contact discharge)
HBM MIL-STD883 Peak pulse power tp=8/20 µs (Note 1,2) Peak pulse current tp=8/20 µs (Note 1,2)
Junction temperature
VESD
PPP IPP...
