LTV-356T - Photocoupler

Download the LTV-356T datasheet PDF. This datasheet also covers the LTV-356T-LITE variant, as both devices belong to the same photocoupler family and are provided as variant models within a single manufacturer datasheet.

General Description

1.1

Key Features

  • Current transfer ratio ( CTR : 50% to 600% at IF = 5mA, VCE = 5V ) High input-output isolation voltage ( Viso = 3,750Vrms ) High collector-emitter voltage ( VCEO = 80V ) Mini-flat package : LTV-356T Safety approval UL 1577 VDE DIN EN60747-5-5 (VDE 0884-5) , CSA CA5A CQC GB4943.1-2011/ GB8898-2011 FIMKO/DEMKO/SEMKO/NEMKO RoHS Compliance All materials be used in device are followed EU RoHS directive (No.2002/95/EC, 2011/65/EU, and 2015/863). ESD pass HBM 8000V/ MM2000V/ CDM2000V MSL class1 Halogen.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (LTV-356T-LITE-ON.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
LTV-356T optoelectronic coupling device UMW
LTV-354 AC Input 4-Pin Mini-Flat Phototransistor Optocoupler UMW
LTV-354T Photocoupler Lite-On Technology
LTV-355T Photocoupler LITEON
LTV-357T Photocoupler Lite-On Technology

Other Datasheets by LITEON

Part Number Description
LTV-352T Photocoupler
LTV-3120 Photocoupler
LTV-3120M Photocoupler
LTV-3120S Photocoupler
LTV-314 Photocoupler

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Photocoupler Product Data Sheet LTV-356T Spec No. :DS70-2001-010 Effective Date: 10/04/2018 Revision: P LITE-ON DCC RELEASE BNS-OD-FC001/A4 LITE-ON Technology Corp. / Optoelectronics No.90,Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C. Tel: 886-2-2222-6181 Fax: 886-2-2221-1948 / 886-2-2221-0660 http://www.liteon.com/opto Photocoupler LTV-356T series 1. DESCRIPTION 1.1 Features Current transfer ratio ( CTR : 50% to 600% at IF = 5mA, VCE = 5V ) High input-output isolation voltage ( Viso = 3,750Vrms ) High collector-emitter voltage ( VCEO = 80V ) Mini-flat package : LTV-356T Safety approval UL 1577 VDE DIN EN60747-5-5 (VDE 0884-5) , CSA CA5A CQC GB4943.
