LMBR4010BST5G
FEATURES
- S- Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable.
- We declare that the material of product pliance with Ro HS requirements.
2. DEVICE MARKING AND ORDERING INFORMATION
Device
Marking
Shipping
R4
10000/Tape&Reel
3. MAXIMUM RATINGS(Ta = 25ºC)
Parameter Reverse Voltage
Forward Current Peak forward surge current (8.3ms)
Symbol Limits Unit
IFSM
4. THERMAL CHARACTERISTICS
Parameter Total Device Dissipation,
FR- 5 Board (Note 1) @ TA = 25ºC Derate above 25ºC Thermal Resistance, Junction- to- Ambient Junction Temperature Storage temperature 1.FR-4 Minimum Pad.
Symbol PD
RΘJA TJ Tstg
Limits Unit
250 m W
2.5 m W/ºC
400 ºC/W
℃
- 55∼+150 ℃
5. ELECTRICAL CHARACTERISTICS (Ta= 25ºC)
Characteristic
Symbol
Min.
Typ.
Max.
Unit
Reverse Breakdown Voltage (IR = 100μA)
-...
