LR7809D Overview
The LRC LR78XXD family is monolithic fixed voltage regulator integrated circuit. They are suitable for applications that required supply current up to 1.
LR7809D Key Features
- Output current up to 1A
- Fixed output voltage of 5V, 6V, 7V, 8V,9V,10V, 12V
- Thermal overload shutdown protection
- Short circuit current limiting
LR7809D Applications
- Output current up to 1A
