SM3100C
FEATURES
- We declare that the material of product pliance with Ro HS requirements and Halogen Free.
- Plastic package has Underwriters Laboratory Flammability Classification 94V-0.
- Low power loss,high efficiency.
- For use in low voltage high frequency inverters,free wheeling, and polarity protection applications.
- High temperature soldering guaranteed:260°C/10 seconds.
- Weight: 0.26g
2. DEVICE MARKING AND ORDERING INFORMATION
Device
Marking
Shipping
SM3100C 3000/Tape&Reel
3. MAXIMUM RATINGS(Ta = 25ºC)
Parameter Maximum repetitive peak reverse voltage Maximum RMS voltage Maximum DC blocking voltage Maximum average forward rectified current at TC = 75°C Peak forward surge current 8.3ms single half sine-wave superimposed on rated load (JEDEC Method)
Typical thermal resistance (Note 1)
Operating junction and storage temperature range
Symbol
Limits
Unit
VRRM
VRMS
IF(AV)
IFSM
RθJA RθJC TJ, TSTG
80 20
- 50 ~+150
A ℃/W
℃
4....
