FK-130RH-09490
FK-130RH-09490 is Carbon-brush motors manufactured by MABUCHI MOTOR.
FK-130RH/ SH OUTPUT:APPROX0.2W~10W
Carbon-brush motors
දత༻్ʗ0"ثػ ¡ϓϦϯλʔ ¡'"9Χολʔ
ࣗಈंిثػ ¡ڸ໘ۦಈ ¡ޫ࣠ௐ
5ZQJDBM"QQMJDBUJPOT0GGJDF"VUPNBUJPO&RVJQNFOUT ¡1SJOUFS ¡'"91BQFS$VUUFS
"VUPNPUJWF1SPEVDUT ¡3FBSWJFX.JSSPS ¡)FBE-JHIU#FBN-FWFM"EKVTUFS
MODEL
VOLTAGE
OPERATING RANGE
NOMINAL
FK-130RH-09490 6 ~ 18 12V CONSTANT
FK-130SH-09450 6 ~ 24 12V CONSTANT
NO LOAD
AT MAXIMUM EFFICIENCY
SPEED CURRENT SPEED CURRENT TORQUE r/min A r/min A g- cm mN- m
OUTPUT W
9000 0.034 6900 0.12 8.5 0.83 0.60
7200 0.035 6100 0.11 10 0.98 0.63
STALL TORQUE CURRENT g- cm mN- m A
40 3.92 0.41
60 5.88 0.47
DIRECTION OF ROTATION 12.4
0.3 REF. 4.3 REF.
2.0xt0.3
UNIT:...
