MACRONIX MX25R8035F
MX25R8035F is 8Mb bits Serial NOR Flash memory, which is configured as 1,048,576 x 8 internally. When it is in four I/O mode, the structure becomes 2,097,152 bits x 4 or 4,194,304 bits x 2. The three bus signals are a clock input (SCLK), a serial data input (SI), and a serial data output (SO).| Part No. | MX25R8035F |
|---|---|
| Datasheet | MX25R8035F Download |
| Manufacturer |  MACRONIX |
| Description | FLASH MEMORY |
| Buy | Stock & Price |
FEATURES
● Ultra Low Power Mode and High Performance Mode● Wide Range VCC 1.65V-3.6V for Read, Erase and Program Operations
● Unique ID and Secure OTP Support
● Multi I/O Support - Single I/O, Dual I/O and Quad I/O
● Program Suspend/Resume & Erase Suspend/Resume P/N: PM2164 Rev. 1.6, October 27, 2017 1 MX25R8035F 1.
FEATURES
Ultra Low Power 8M-BIT [x 1/x 2/x 4] CMOS MXSMIO® (SERIAL MULTI I/O) FLASH MEMORY GENERAL● Supports Serial Peripheral Interface -- Mode 0 and Mode 3
● 8,388,608 x 1 bit structure or 4,194,304 x 2 bits (two I/O mode) structure or 2,097,152 x 4 bits (four I/O mode) structure
● Equal Sectors with 4K byte each, or Equal Blocks with 32K/64K byte each - Any Block can be erased individually
● Single Power Supply Operation - Operation Voltage: 1.65V-3.6V for Read, Erase and Program Operations
● Latch-up protected to 100mA from -1V to Vcc +1V PERFORMANCE
● High Performance - Fast read - 1 I/O: 108MHz with 8 dummy cycles - 2 I/O: 104MHz with 4 dummy cycles, equivalent to 2...
