ESDSLC0524F
Features
- Transient protection:
- IEC 61000-4-2 (ESD) ±25k V (Air), ±20k V (Contact)
- IEC 61000-4-5 (Lightning) 5A (8/20µs)
- Uni-directional ESD protection of four lines
- Reverse working voltage, VRWM: 5V
- Capacitance: 0.6p F (typical)
- Clamping voltage: 16V (max)
- Reverse leakage current: 900n A max at VR = 5V
- Solid-state silicon-avalanche
ESDSLC0524F 4-Line Uni-directional Low Capacitance ESD
DFN2510-10
Applications
- HDMI 1.3,HDMI1.4, and HDMI 2.0
- USB 2.0, USB 3.0
- Digital Visual Interface (DVI)
Body Marking and Pin Layout Marking Code
0524F
Mechanical Data
- Package: DFN2510-10
- Moisture Sensitivity Level 1, per J-STD-020
- Halogen Free. “Green” Device (Note1)
- Epoxy Meets UL 94 V-0 Flammability Rating
- Lead Free Finish/Ro HS pliant ("P" Suffix Designates
Ro HS pliant. See Ordering Information)
Simplified Outline
NC GND NC
I/O
I/O GND I/O
I/O
Transparent top view
Internal Structure
45 3,8
Ordering Information
Product Name
Reel...
