Datasheet Summary
Features
- Split Gate Trench MOSFET Tenchnology
- Excellent Package For Heat Dissipation
- High density cell design for low RDS(ON)
- Moisture Sencitivity Level 1
- Halogen Free. “Green” Device (Note1)
- Epoxy Meets UL 94 V-0 Flammability Rating
- Lead Free Finish/RoHS pliant (Note2)("P" Suffix Designates
RoHS pliant. See Ordering Information)
Maximum Ratings
- Operating Junction Temperature Range : -55°C to +150°C
- Storage Temperature Range: -55°C to +150°C
- Thermal Resistance: 40°C/W Junction to Ambient(Note3)
- Thermal Resistance: 0.55°C/W Junction to Case
Parameter
Drain-Source Voltage Gate-Source Volltage
TC=25°C Continuous Drain Current
TC=100°C Pulsed Drain Current（Note4）
To...
