S5ML Overview
Key Specifications
Mount Type: Surface Mount
Pins: 2
Key Features
- Halogen Free. “Green” Device (Note
- For Surface Mount Applications
- Glass Passivated Chip Junction
- High Current Capability
- Epoxy Meets UL 94 V-0 Flammability Rating
| Part | S5ML |
|---|---|
| Description | 5 Amp General Purpose Rectifier |
| Manufacturer | Micro Commercial Components |
| Size | 670.97 KB |
Pricing from 0.137 USD, available from Future Electronics and DigiKey.Powered by Octopart
Price & Availability
| Seller | Inventory | Price Breaks | Buy |
|---|---|---|---|
| Future Electronics | 228000 | 3000+ : 0.137 USD 6000+ : 0.135 USD 12000+ : 0.134 USD 15000+ : 0.132 USD |
View Offer |
| DigiKey | 2183 | 1+ : 0.71 USD 10+ : 0.43 USD 100+ : 0.2839 USD 500+ : 0.21588 USD |
View Offer |
Similar Parts
| Part Number | Manufacturer | Description |
|---|---|---|
| S5M | Sunmate | SURFACE MOUNT RECTIFIER DIODES |
| S5M | PanJit Semiconductor | SURFACE MOUNT RECTIFIER |
| S5MC | SMC | 5.0A SURFACE MOUNT GLASS PASSIVATED RECTIFIER |
| S5M | TIPTEK | 5A SURFACE MOUNT RECTIFIER |
| S5M | SEMTECH | Surface Mount General Rectifiers |
