B0530WS Datasheet | MLS Microelectronics

Features - Low Forward Voltage Drop - Guard Ring Construction for Transient Protection - High Conductance - Also Available in Lead Free Version SCHOTTKY BARRIER DIODE D2 D1 SOD-323 top view Schematic diagram - SE + Marking and pin assignment Maximum Ratings(Ta=25℃ unless otherwise noted) Symbol VR VRRM VRWM VR(RMS) IO IFSM PD RΘJA TJ Tstg dv/dt Parameter Reverse Voltage Maximum recurrent peak reverse voltage Working Peak Reverse Voltage RMS Reverse Voltage Average Rectified Output Current Non-repetitive Peak Forward Surge Current@t= 8.3ms Power Dissipation Thermal resistance junction to ambient air Operating Junction Temperature Range Operation Junction and Storage Temperature Range Voltage rate of change Value 21 0.5 5.5 200 500 -40~+125 -55~+150 1000 Unit V A A m W °C/W °C °C V/μs ELECTRICAL CHARACTERISTICS(Ta=25℃ unless otherwise specified) Symbol Parameter V(BR) Reverse voltage Reverse voltage leakage current Forward voltage Ctot Total capacitance Condition IR=500u A VR=15V VR=20V VR=30V IF=0.1A IF=0.5A VR=1,f=1MHz Ordering Information (Example) Type Package Marking Minimum SOD-323...
