BCW61
Features
- Low current
- Low voltage
- General Purpose Transistor
Transistor (PNP)
BCW61A: BA C
BCW61B: BB C
SOT-23 top view
BCW61C: BC C
BCW61D: BD C
Schematic diagram
Maximum Ratings (Ta=25℃ unless otherwise noted)
Symbol
VCBO VCEO VEBO IC PC RΘJA TJ,Tstg
Parameter
Collector-Base Voltage Collector-Emitter Voltage Emitter-Base Voltage Collector Current Collector Power Dissipation Thermal Resistance From Junction To Ambient Operation Junction and Storage Temperature Range
Value
-32 -32 -5 -100 250 500 -55~+150
Unit
V V V m A m W °C/W °C
Ordering Information (Example)
Type
BCW61A
BCW61B BCW61C BCW61D
Package
SOT-23 SOT-23 SOT-23 SOT-23
Marking
BA BB BC...
