MBRX0560
MBRX0560 is SCHOTTKY BARRIER DIODE manufactured by MLS Microelectronics.
- Part of the MBRX0520 comparator family.
- Part of the MBRX0520 comparator family.
MBRX0520-MBRX0560
SCHOTTKY BARRIER DIODE
Features
- Low Forward Voltage
- Lead Free Finish/Ro HS pliant
- For Surface Mount Application and High Current Capability
S1 D2
SOD-32D31 top view
Marking
MBRX0520:2.
MBRX0530:3.
MBRX0540:4 .
Schematic diagram
MBRX0560:6.
- 2.
+-
3D.5 +
- 4.
+-
6.
+
The marking bar indicates the cathode
Maximum Ratings ( Ta=25℃ unless otherwise noted )
Symbol
Parameter
VRRM VR(RMS) IO IFSM PD RΘJA TJ Tstg
Peak Repetitive Reverse Voltage RMS Reverse Voltage Average Rectified Output Current Non-repetitive Peak Forward Surge Current@t= 8.3ms Power Dissipation Thermal Resistance from Junction to Ambient Operating Junction Temperature Range Storage Temperature Range
MBRX MBRX MBRX MBRX 0520 0530 0540 0560
-40~+125
-55~+150...
