B1209S-1WR3
FEATURES
- Continuous short-circuit protection
- No-load input current as low as 8m A
- Operating ambient temperature range:
-40℃ to +105℃ Patent Protection
- High efficiency up to 85%
UL 62368-1
Report
Report
EN 62368-1
BS EN 62368-1
CB Ro HS
IEC 62368-1
- I/O isolation test voltage: 1.5k VDC
- Industry standard pin-out
B_S-1WR3 series are specially designed for applications where an isolated voltage is required in a distributed power supply system. They are suitable for: pure digital circuits, low frequency analog circuits, relay-driven circuits and data switching circuits.
Selection Guide
Certification
Part No.
--
UL/EN/BS EN
UL/EN/BS EN/IEC
-UL/EN/BS
EN/IEC
B0303S-1WR3 B0305S-1WR3 B0309S-1WR3 B0312S-1WR3 B0315S-1WR3 B0324S-1WR3 B0503S-1WR3 B0505S-1WR3 B0509S-1WR3 B0512S-1WR3 B0515S-1WR3 B0524S-1WR3 B1203S-1WR3 B1205S-1WR3 B1209S-1WR3 B1212S-1WR3 B1215S-1WR3 B1224S-1WR3 B1505S-1WR3 B1509S-1WR3 B1512S-1WR3 B1515S-1WR3 B1524S-1WR3 B2403S-1WR3 B2405S-1WR3 B2409S-1WR3...
