Full PDF Text Transcription for MAX8881 (Reference)
Note: Below is a high-fidelity text extraction (approx. 800 characters) for
MAX8881. For precise diagrams, and layout, please refer to the original PDF.
19-1679; Rev 0; 4/00 12V, Ultra-Low-IQ, Low-Dropout Linear Regulators with POK General Description The MAX8880/MAX8881 are ultra-low supply current, low-dropout linear re...
View more extracted text
he MAX8880/MAX8881 are ultra-low supply current, low-dropout linear regulators, capable of delivering up to 200mA. They are designed for battery-powered applications where reverse battery protection and long battery life are critical. These regulators’ low 3.5µA supply current extends battery life in applications with long standby periods. Unlike PNP-based designs, a 2Ω PMOS device maintains ultra-low supply current throughout the entire operating range and in dropout. The parts are internally protected from output short circuits, reverse battery connection, and thermal overload. An internal powerOK (POK) comparator indica
